We provide high quality Ad circuit board routing service for more than 3000 customers. We have more experience experts providing high quality work and independently developed software to enhance design efficiency. Advanced ad circuit board routing traces and vias in a PCB design is often considered a straightforward task. Following the importation of the china ad circuit board routing and arrangement of components, it may appear relatively uncomplicated to commence interconnecting the components with copper.
The item " Ad Circuit Board Routing " denotes the utilization of copper traces on either the surface layer or inner layers of a printed circuit board to establish connections between components.Our company no limit to MOQ, meet different customer demands by all means. Ad circuit board routing made in china.The complexity of a device is contingent upon an array of factors, including but not limited to functionality, performance requirements, and environmental considerations, all of which collectively determine the appropriate wiring design for the newest ad circuit board routing.
Basic information:
Item name: ad circuit board routing
HDI Layer Count: 4L-32L mass production, 34L-64L quick-turn
Material: High Tg material (Recommend Shengyi Material)
Finished Board Thickness: 0.8-4.8mm
Finished Copper Thickness: Hoz-8oz
Max. Board Size: 600X800mm
Min. Drilling Size: 0.15mm, 0.1mm(laser drilling)
Blind/Buried vias depth ratio: 1:1
Min. Line Width/Space inner: 2/2mil, outer 3/3mil
Surface Finish: ENIG, Immersiong Silver, Immersion Sn, Plated Gold, Plated Sn, OSP ect.
Standard: IPC Class 2, IPC Class 3, Millitary
Ad circuit board routing features:
The state-of-the-art wiring tools, which are at the forefront of technology and designed to facilitate compliance with fundamental PCB wiring guidelines, offer an interactive experience. In other words, these tools are semi-automated, enabling users to define signal routes and have the routing tool automatically place traces that adhere to design rules and specifications.
